The Versatile flow wrap solution is efficient and suitable for products in single or multiple units, with or without tray. The output varies based on product specifications and feeding system.
Versions:
- Right-Left/Left-Right
- Suitable for high Production demands
- Standard/Stainless Steel
- Mechanical/Servo
zoom_in
| Speed | 60 – 220 packs per min |
| Product width | 20mm – 200mm |
| Product height | 10mm – 70mm |
| Product length | 50mm – 400mm |
| Wrapper cutoff length | 270mm – 350mm |
| Max reel width | 280mm – 600mm |
| Max reel diameter | 300mm |
Please contact us to discuss requirements that differ from the above specifications.
- All ball bearings lubricated & sealed for life-time use
- Flexibility to run different product with fast change over.
- Special jaw profile for high integrity sealing
- Temperature control of sealing units through PLC
- Dwell adjustment in running condition
- Food contact parts from stainless steel and food grade plastics
- Transparent jaw guards with safety interlock
- “Rapid response” onsite production support availability
- Two-way print mark registration and control
- Positive wrapper feed drive
- Auto web alignment
- Air extraction
- Air jet / mechanical gusseting
- Bag hole punch
- Zig-zag knife
- End folding device
- Counting, auto collation & separation at outfeed
- Extended infeed and outfeed conveyors
- No product – No bag (Only for Electronic Machine)
- Stainless steel guards and covers
- CE Compliance machine
- Touch screen HMI
- Remote process diagnostics (direct connectivity)(Only for Electronic Machine)
- Extended in-plant “live production” support
- Preventive maintenance contract
